Hello! We decided to talk about disk mounting again. Today we’ll tell you how to work with LVM containers. Here’s a short manual so you don’t have to Google and waste time during an urgent investigation.

1️⃣ Step 1. Check information about the existing binary image:

fdisk -l ./source.raw

(How to get a binary image from VMDK, VDI, VHD and other formats, we wrote about here).

We see:

Device     Boot   Start   End   Blocks    Id System
disk.img1     *   1     13     104391    83 Linux
disk.img2       14     2491   19904535 8e Linux LVM

Here we are interested in partition 8e — Linux LVM.

2️⃣ Step 2. Mount the source image to a virtual loop interface:

sudo losetup -f -P source.raw

As a result, a virtual loop-device should appear. Check its parameters:

sudo lsblk -f
loop20
├─loop20p1
├─loop20p2        ext4        1.0            f32150ec-1a4e-4871-9c1b-43219f525536
└─loop20p3        LVM2_member LVM2 001       iiB6Sv-7IZv-k329-ednM-h4Nr-tZQk-NJrMoE

(*device indices may differ depending on hardware configuration)

3️⃣ Step 3. Scan the obtained device for LVM partitions:

sudo pvscan --cache

We see:

pvscan[3874] PV /dev/loop20p3 online.

After that, run the command:

sudo vgs (to view volume groups):

ubuntu-vg   1   1   0 wz--n- 18.22g    0

and sudo lvs (to view logical volumes):

ubuntu-lv ubuntu-vg -wi-a----- 18.22g

4️⃣ Step 4. Activate the LVM partition:

sudo vgchange -ay

1 logical volume(s) in volume group "ubuntu-vg" now active

5️⃣ Step 5. Then mount using the well-known mount command (remember the -ro flag to avoid making changes):

sudo mkdir /mnt/lvm-disk
sudo mount -ro /dev/mapper/ubuntu--vg-ubuntu--lv /mnt/lvm-disk

As a result, we get the mounted partition in the specified folder and perform further actions.

To unmount LVM, use the reverse sequence of commands:

sudo umount /mnt/backup-restore (unmount the partition)
sudo lvchange -an /dev/mapper/ubuntu--vg-ubuntu--lv (deactivate LVM)
sudo losetup -d /dev/loop20 (detach the device)
sudo pvscan --cache (scan the disk system to update the state)

Another post for the collection of useful manuals. To be continued!
